SODICK TR650EH2 (YR 2012) Used Hybrid Injection Moulding Machine

SODICK TR650EH2 (YR 2012) Used Hybrid Injection Moulding Machine for sale

Available: 2 Units

Model: TR650EH2

Year: 2012

Screw diameter: 50mm

Plunger diameter: 60mm

Theoretical injection volume: 565.2cm3

Max. clamping force: 6374kN

Min./max. mold thickness: 650/1210mm

Daylight: 1550mm

Tie-bar spacing: 980×980mm

Max. injection pressure: 176MPa

Max. injection speed: 300mm/s

Machine weight: 27000kg (Mold clamping parts7000/ Clamping force parts20000)

Machine size (L×W×H): 9180 × 2130 × 2185

Please contact us for more details and price.
