Nissei ASB

NISSEI PF8-4B (YR 2008) Used Pf-Type Biaxial Orientation Injection Stretch Blow Moulding Machine

NISSEI PF8-4B (YR 2008) Used Pf-Type Biaxial Orientation Injection Stretch Blow Moulding Machine

NISSEI PF8-4B (YR 2008) Used Pf-Type Biaxial Orientation Injection Stretch Blow Moulding Machine for sale

Number of Cavity: Injection cavity 8  | Blow Cavity: 4

Injection unit: IU-35

Hydraulic circuit pressure: 14,0 MPa

Screw diameter: 64mm

Injection capacity: 515cm3/shot

Injection pressure: 98MPa

Injection rate: 269cm3/sec

Screw stroke: 160mm

Unit stroke: 240mm

Screw rotation speed: 150 r/min

Includes :

- 2xmoulds for mineral water bottle

- Dehumidifying resin dryer with hopper and auto-loader

- Spare parts

The machine is in good working condition. Please contact us for more details and price.
